The performance of Chalco 5083 5052 6061 precision machined aluminum plate is high precision aluminum alloy plate with greatly improved flatness and thickness tolerance, as well as reduced residual stress. Offering reduced cutting time, less annealing after processing and higher yield rates, we helps to reduce customer’s costs.
Alloy: 5083 5052 6061
Temper: F, H111, H112, T6, T651,T451
Thickness: 6mm up to 300mm
Length: 500mm up to 6000mm
Characteristics of Chalco 5083 5052 6061 precision machined aluminum plate:
1. Improved manufacturing processes offer increased flatness
2. A distinctive heat treatment process greatly reduces internal residual stress.

Chemical Composition of Chalco 5083 5052 6061 precision machined aluminum plate
Alloy	Si	Fe	Cu	Mn	Mg	Cr	Ni	Zn	Ti	Others		Aluminum
										Each	Total
EN AW-5052	0.25	0.40	0.10	0.10	2.2--2.8	0.15--0.35	－	0.10	－	0.05	0.15	Remainder
EN AW-5083	0.40	0.40	0.10	0.40-1.0	4.0-4.9	0.05-0.25	－	0.25	0.15	0.05	0.15	Remainder
EN AW-6061	0.4-0.8	0.70	0.15-0.40	0.15	0.8-1.2	0.04-0.35	－	0.25	0.15	0.05	0.15	Remainder

Application of Chalco 5083 5052 6061 high strength precision aluminum plate:

Used in making semiconductor manufacturing equipment, LCD manufacturing equipment, Solar panel manufacturing equipment, Robots, Medical equipment, OA equipment, Optical equipment, Various molds, Tools, etc.
