Product introduction of
6061 T651 high precision super flat aluminum sheet
1. The surface is polished with more than 400 mesh, without milling surface, and can be directly anodized.
2.The thickness tolerance can reach 0.05mm, flatness 0.05mm/m2.
3. The use of special technology to control the residual stress in the minimum, greatly reduce the deformation, greatly reduce the cost of machining for customers.
6061 T651 high precision super flat aluminum sheet
2: Accuracy of
6061 T651 high precision super flat aluminum sheet
|
Grade |
Thickness range |
Thickness tolerance |
Flatness |
A+
|
3mm-12mm |
±0.05mm |
0.1mm/m2 |
|
15mm-20mm |
±0.05mm |
0.1mm/m2 |
|
25mm-40mm |
±0.1mm |
0.1mm/m2 |
|
A |
3mm-12mm |
±0.1mm |
0.1mm/m2 |
|
15mm-20mm |
±0.1mm |
0.2mm/m2 |
|
25mm-40mm |
-0.1-0.2mm |
0.2mm/m2 |
General specification of
6061 T651 high precision super flat aluminum sheet:
|
Thickness |
Width x Length(mm) |
|
3mm-20mm |
2000-2500x5000-6200 |
|
25mm-30mm |
1525x5000 |
6061 T651 high precision super flat aluminum sheet use
Automatic equipment, fixture fixture (high temperature furnace not deformation), precision spare parts, medical instruments, auto parts, aerospace, military supplies, various molds, etc
