Chalco 5052 precision machined rolled aluminum plate is used in many areas where high standard are not set on strength. However, this alloy has good features that make this materials useful in many areas.

Characteristics of Chalco 5052 precision machined rolled aluminum plate:
1.    Two surfaces precision milled, foiled on both sides.
2.    Very good anodizing capacity
3.    Seawater resistant
4.    Very good wedability Specification of Chalco 5052 5052 precision machined rolled aluminum plate:

Alloy Composition:
Alloy:  EN573-3/3.3547   5052
Material features: H111, H112

Material Properties:
Machinability:   good
Weldability:    Very good
Anodic oxidation properties: Good, not decorative
Polishability:      good
Corrosion resistance: Very good
WEDN machining: good

Typical Mechnical Properties:
Tensile strength Rm: 165--215 Mpa
0.2% Yield strength Rp0.2:  Above 65 Mpa
Breaking elongation A5%:  19--25
Brinell hardness HBW:     Above 46

Thickness ranges and sizes:

Plate thickness between  6mm---150mm
Standard sizes are:
Thickness     ×    Max. Width     ×  Max. Length
>=6mm       ×   2500mm         ×  6000mm
Other dimension available on request

Tolerance:

Surace:   Precision milled
Surface roughness Ra  <=0.4um
Thickness tolerance: +/-0.05mm
Flatness:     >6—100mm  thickness<=0.12mm
Tolerance in width: -0+10mm
Tolerance in length: -0+15mm
Application of Chalco 5052 precision machined rolled aluminum plate:

Shipbuilding, the very good resistance to the aggressive influence of seawater means, 5052 precision machined rolled aluminum plate are often used for technical housing in the shipping industry.

Mechanical engineering, 5052 precision machined rolled aluminum plate provide a cost-effective alternative for lightly loaded base and support plates.

Welded constructions, the very good weldability of 5052 precision machined rolled aluminum plate means that, the materials can be used in a variety of welded structures.

Container and plant construction, due to good corrosion resistance and workablity(bending, edges) of 5052 precision machined rolled aluminum plate, they are widely used for the production of media-filled containers. Containers are subject to pressure vessel regulations are usually prescribed material state H112.
