Alloy composition: 5083 alloy, According to GB/T3190 or EN573-3 Standard
Typical mechanical properties
Tensile strength Rm  MPa (N/mm2) 220 - 300
Yield strength Rp 0.2 MPa (N/mm2) 110 - 140
Elongation A5 %  A5 % 10-20
Brinell hardness HB  HB 70-85
Typical physical properties
Density  g/cm3 2.66
Thermal conductivity  W/(mk) 110 - 140
Conductivity m/Ωmm2 16 - 19
Modulus of elasticity GPa 70
Thermal expansion coefficient  *10-6 /K 24.2
Product Classification
   Tolerance



Milling surface
Aluminum plate Thickness range
Maximum width
Maximum length  6 mm – 250 mm
2500 mm
6000 mm  Thickness tolerance
Width tolerance
Length tolerance
Flatness
Surface roughness + / - 0.12mm
0/+6 mm
0/+10 mm
≤0.35 mm/m (T≤15mm)
≤0.13mm/m (T>15mm)
≤0.4 μm
Typical application

• Instrument and equipment appearance
• Parts with apparent requirements
• Products that require surface mechanical properties
   Automation equipment
• Tooling fixture
• Fixture inspection tools, etc.
